Operation
Dynamics of the hydraulic move-
ments
WARNING
Risk of injury due to delayed response from the
truck!
If a low dynamic is set, the lifting system responds
after a delay when the operating device is released,
even in an emergency. The fork carriage does not
stop immediately upon release. It only stops after
approximately one second. This behaviour may
also occur when specific settings are configured for
the "Dynamic Load Control" assistance system.
– Work with particular attention and care.
The authorised service centre can reduce
the dynamics of the hydraulic movements
to adapt the hydraulic movements to the
application requirements. The hydraulic
system movement will then respond more
slowly to the actuation of the operating device.
Maximum dynamics are suitable for applica-
tions that require the load pick up system to
respond quickly and directly. Minimum dy-
namics are suitable for applications in which
impacts must be avoided, e.g. when moving
fragile goods.
Maximum dynamics (standard setting)
• The hydraulic movement immediately
follows the actuation of the operating
device.
• When the operating device is released,
the hydraulic movement decelerates very
quickly.
The fork carriage quickly comes to a stand-
still.
Minimum dynamics
• The hydraulic movement accelerates very
slowly when actuating the operating device.
• The hydraulic movement follows the actua-
tion of the operating device very slowly.
• When the operating device is released,
the hydraulic movement only decelerates
slowly.
The fork carriage therefore continues to run
for some time before the movement comes
to a standstill.
