4
Dynamic Load Control
– Contact the authorised service centre on
this matter.

Lift mast vertical position (variant)

CAUTION
Risk of damage to property due to the lift mast
colliding with racks or other objects!
– Before using the "automatic mast vertical posi-
tioning" comfort feature, position the truck at a
sufficient distance from racks and other objects.
Goods such as paper rolls can be lowered
vertically with precision using the "automatic
mast vertical positioning" comfort feature,
thereby avoiding damage when unloading.
"Automatic mast vertical positioning" functions
when tilting forwards. A further variant is
available which also functions when tilting
backwards. The tilt cylinders run into the
end stops gently to prevent hard vibrations
and impacts. Oscillating motions of the
truck are minimised, thus increasing work
safety. Automatic mast vertical positioning
reduces wear on various components, thereby
reducing repair costs.
– Push the "automatic mast vertical position-
ing" softkey .
The symbol appears in the display.
– Tilt back the lift mast until it reaches the end
stop.
– Tilt the lift mast forwards.
The lift mast stops in the vertical position.
NOTE
The lift mast also stops in the vertical position
if it is tilted forwards by ≥ 3° from a backward
tilt.
210 56368011531 EN - 06/2019 - 02
Operation
