Operation
Reduction of dynamics according to
the load weight
WARNING
Risk of accident due to the slow response of the
lifting system!
If the hydraulic movements are configured to use
low dynamics, the lifting system responds after a
delay when the operating device is released, even
in an emergency. The fork carriage does not stop
immediately; instead, it takes approx. one second.
This behaviour may also occur when specific
settings are configured for the "Dynamic Load
Control" assistance functions.
– Work with particular attention and care.
The load weight-based reduction of the
dynamics applies at the beginning and the
end of the lifting movement.
The following requirements must be met so
that the assistance function can be switched
on:
• The fork carriage must be at least 2.1 m off
the ground, or in the main lift for NiHo and
triplex lift masts.
• The carried load must exceed 50% of the
nominal load.
The tilting movements and driving movements
now happen more slowly.
The dynamics of the lifting movement are
reduced at the start and at the end of the
lifting movement. As soon as the load is
located above the main lift, the driving speed
is reduced to 5 km/h.
This supports inexperienced drivers with their
work. Damage to the truck, the load and the
surroundings is reduced.
"Silent Lift" fork wear protection
(variant)
The "fork wear protection" variant ensures
that the fork arms do not touch the ground.
The correct height for inserting the forks into a
pallet can also be configured.
56368011531 EN - 06/2019 - 02
Dynamic Load Control
