Basic Settings

5.1.1

Overview

This product can measure the flow velocity, volumetric flow rate, mass flow rate, calorie, and
various diagnostic values.
Refer to the table below for the specification codes for communication/input-output and
connection terminals, and input and output for each terminal.
Communication
and I/O
code
F0 -F
P/Sout: Pulse output or status output
The position of Communication and I/O code:
Integral Type: A XG□□□-□□□□□□□□□□□□□□-□■■□□
Remote transmitter: AXG4A-□□□□□□□■■□□
5.1.2

Connection of Process Value to AI Function

The process value calculated by STB and DTB are output to a specific channel, respectively. By
selecting the channel used in the AI function block, a process value is obtained from STB and
DTB.
The relation of the channel for each process value and the channel which can be selected from
each AI function block is shown in the figure below.
Connection Terminal
I/O1 +/- I/O2 +/-
F
OUNDATION
P/Sout
Fieldbus
(Passive)
communication
AXW □□□ - □□□□□□□□□□□□□□ - □■■□□
AXW □□□ G - ■□□□□□ - □□□□ - □□□
AXW4A-□□□□□□□■■□□
