The default value of "All block target mode" and the value right after "Restore" is "Not execute".
Menu path (at the following five points on the menu tree of the display)
Device setup ► Block mode ► (see below)
Device setup ► Diag/Service ► (see below)
Display
Device setup ► Easy setup wizard ► (see below)
Device setup ► Detailed setup ► (see below)
Device setup ► Detailed setup ► Fieldbus info ► (see below)
Block Relative
Name Index
- -
Select from the table below.
Selection
Display
O/S
Restore
Not Execute
5.7.7

microSD Card Setting

If the optional code MC is selected, the backup parameters and logging data can be used by
inserting the dedicated microSD card into the display.
For details about backing up parameters and logging data, refer to Section 5.11.
(1) Removing the microSD card
IMPORTANT
If "Unmount" is not executed on the software when removing the microSD card, it may cause
data stored on the microSD card to be erased or the device to operate abnormally.
The microSD card can be removed with the following parameter.
Menu path
Display
Device setup ► microSD ► (see below)
Parameter
Unmount
From the table below, select whether to remove the microSD card.
Selection
Cancel
Execute
Parameter
Display
All block target
-
mode
F
OUNDATION
Fieldbus
Set the target mode of each block to O/S. If this value is written twice or
-
more before [Restore], O/S mode is stored in the transmitter.
Restore each block to the target mode before executing this function.
Not execute
Specifies the removal of the microSD card.
Cancels the removal of the microSD card.
Makes it possible to remove the microSD card in safety.
<5. Functions>
F Fieldbus
OUNDATION
Description
Description
Description
122
Description
Switch the target mode of
RB/STB/DTB/LTB/MTB/FB
(AIFB,DIFB) at once.
IM 01E21A02-03EN
