Restore Voltage
Charge Current (Max)
Auto Equalized Charge
Auto Equalized Charge
Interval
Equalized Charge Time
Battery Test Fail Voltage
Battery Test Duration
Auto Battery Test Interval
Low Temperature Alarm
High Temperature Alarm
Installation Date
Next Replacement Date

7.10.5 Parallel Setting

Path:
SETUP
After entering the PARALLEL SETTING screen*
Please contact Delta customer service for assistance.
NOTE:
1
*
means that the Administrator password is needed. For password information,
please refer to 7.5 Password Entry.
Item
Restore the charging voltage.
Set up the maximum charge current.
Enable or disable the auto-equalized charge.
Set up the auto equalized charge interval.
Set up the equalized charge time.
Set up the battery test fail voltage. When the battery
voltage is under the test fail voltage, it means battery fail.
Set up how long the battery test should last.
Set up the battery test interval.
Enable or disable the low temperature alarm. If enabled,
set up the temperature.
Enable or disable the high temperature alarm. If enabled,
set up the temperature.
Record the battery installation date.
Set up the battery replacement date.
Description
NOTE:
1. The item will only show up if the Battery Type
is set as 'LiB (Integration)'.
2. If the Battery Type is set as 'LiB (Dry
Contact)', the item will not show up and the
item Charge Current (Max)' will shift left.
1
7-47
7
LCD Display & Settings
