Internal View - Delta Modulon DPH Series User Manual

10" Color Touch Panel
Tri-color LED Indictor
Door Switches
1
Pull Up Pull Up
2.6

Internal View

WARNING:
Only authorized Delta engineers or service personnel can perform installation,
wiring, panel & cover removal, maintenance and operation. If you want to execute
any action mentioned above by yourself, the action must be under the supervision
of authorized Delta engineers or service personnel.
Stands
(Figure 2-2: UPS Front View)
2
90° 90°
(Figure 2-3: How to Open the UPS Front Doors)
2-7
2 Introduction
Stands
1
Pull Up Pull Up
2
90° 90°
