Delta Modulon DPH Series User Manual page 15

No.
UPS
1
on the inner side of the UPS's two front doors before
shipment)
User Manual
2
RS-232 Cable (1.8 meters)
3
Parallel Cable (5 meters)
4
Test Report
5
Key
6
M12 Screw (used for input/ output/ battery/
7
grounding wiring)
8
USB Cable
9
4-Pin Dry Contact Terminal Block
(used for REPO dry contacts; please refer to
10
Figure 4-3)
6-Pin Dry Contact Terminal Block
(used for MODBUS and BMS ports located at the
11
rear of the touch panel; please refer to Figure 4-17)
8-Pin Dry Contact Terminal Block
(used for (1) external battery temperature dry
12
contacts and (2) external switch/ breaker status dry
contacts; please refer to Figure 4-3)
10-Pin Dry Contact Terminal Block
(used for input/ output dry contacts; please refer to
13
Figure 4-3)
4. If there is any damage or anything missing, please immediately contact the dealer
from whom you purchased the unit.
5. If the UPS needs to be returned, carefully repack the UPS and all of the accessories
using the original packing material that came with the unit.
Item
2-3
2 Introduction
Q'ty
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
(two copies placed inside
the UPS cabinet)
64 PCS
8 PCS
1 PC
1 PC
1 PC
2 PCS
2 PCS
