5
Installation and Wiring
3
Pull out the power module from the slot (two people are required) (see Figure 5-40).
When the power module cannot be pulled out any more, press the lock (see Figure
5-41) on the left side of the power module to continuously pull it out from the UPS
cabinet.
Power Module
(Figure 5-40: Remove the Power Module)
Press the Lock
(Figure 5-41: Press the Lock of the Power Module)
5-37
