Delta Modulon DPH Series User Manual page 134

8
Go to SETUP
UPS-1.1
MODE SETTING
9 Tap the icon (
Main Screen.
10 Tap the ON/ OFF Button (
to power on the UPS's inverter. Please select 'YES'.
UPS-1.1
Power Flow
11
After selection of 'YES' to start up the UPS's inverter, each power module will start
up and perform self-inspection. After the self-inspection is completed, the UPS will
automatically transfer to run in Frequency Conversion mode and the output frequency
will be the same as setup value. Now, the tri-color LED indicator illuminates green and
the following screen appears. For the tri-color LED indicator's location, please refer to
Figure 2-11.
Modulon DPH Series
Mode Setting
WARNING:
Please note that, once you select 'Frequency Conversion' mode via the
LCD, the UPS will run in Standby mode and the output will be terminated.
MEASUREMENT SETUP MAINTENANCE
Mode Setting
Select to change system mode
On-Line Green
(Figure 6-30: Select Frequency Conversion Mode)
) located in the upper left corner of the screen to go back to the
UPS-1.1
MEASUREMENT SETUP MAINTENANCE
POWER ON ?
Yes
(Figure 6-31: Power on Reminder Screen)
Frequency Conversion.
LOG IN EVENT LOG
Administrator
Energy
ECO
Recycle Conversion
) and the following screen will pop up to ask if you want
LOG IN EVENT LOG
Administrator
No
6-24
10:15
Sep 25,2018
Standby
Frequency
10:15
Sep 25,2018
Standby
