(Internal View with Two Front Doors Open &
Two Switch Panels Removal)
Battery Input
N
Terminals
(Figure 2-8: Wiring Terminals_ Battery Input)
(Internal View with Two Front Doors Open &
Two Switch Panels Removal)
Grounding Terminals
(
&
)
(Figure 2-9: Wiring Terminals_ Grounding)
Modulon DPH Series
2-10
