Delta Modulon DPH Series User Manual page 176

Main Menu Icon Description
Tap the icon to go to the Measurement Menu. In the menu, you can
check the UPS's readings including the following:
1. Main Input
2. Bypass Input
3. Inverter Output
4. Power Module Summary
MEASUREMENT
5. UPS Output
6. Battery Status
7. EMS
For more information, please refer to 7.9 Check System Readings.
Tap the icon to go to the Setup Menu. In the menu, you can set up
the following:
1. Bypass Setting
2. Mode Setting
3. Output Setting
4. Battery & Charging Setting
5. Parallel Setting
SETUP
6. Dry Contact Setting
7. General Setting
8. IP Setting
9. Control
10. EMS Setting
For more information, please refer to 7.10 UPS Settings.
Tap the icon to go to the Maintenance Menu. In the menu, you can
(1) check the warning events/ historical events/ statistics/ relevant
temperature readings/ firmware versions, (2) execute the manual
battery test, (3) clear the statistics/ historical events/ battery test
In the Maintenance Menu, it includes the following items.
1. Warning
2. Historical Event
MAINTENANCE
3. Statistics
4. Test
5. Clear
6. Advanced Diagnosis
7. Version & S/N
For more information, please refer to 7.11 System Maintenance.
Modulon DPH Series
7-18
