UPS-1.1
MEASUREMENT
DRY CONTACT SETTING
Event
1
2
3
4
Input Dry
Contact No.
Input Dry Contact 1
Input Dry Contact 2
Input Dry Contact 3
Input Dry Contact 4
UPS-1.1
MEASUREMENT
DRY CONTACT SETTING
Event
1
2
3
4
5
6
SETUP
MAINTENANCE
Dry Contact Setting
INPUT
OUTPUT
None
None
None
None
Event Selection
Select one of the following events as
the setting for each input dry contact.
1. None
2. Generator status
3. Battery ground fail
4. External battery breaker detection
5. Charge Off (Positive)
6. Charge Off (Negative)
SETUP
MAINTENANCE
Dry Contact Setting
INPUT
OUTPUT
None
None
None
None
None
None
7-49
7
LOG IN
EVENT LOG
Administrator
Type
Normally Open
Normally Open
Normally Open
Normally Open
Set up NO (normally
open) or NC (normally
closed) for each input
dry contact.
LOG IN
EVENT LOG
Administrator
Type
Normally Open
Normally Open
Normally Open
Normally Open
Normally Open
Normally Open
LCD Display & Settings
10:15
Sep 25,2018
Bypass
Type
10:15
Sep 25,2018
Bypass
