No. Icon/ Text
10
11
System Status
12
13
14
Bypass
15
Mains
Modulon DPH Series
Button
Function
(Yes or Display
No) (Yes or No)
Summary
EMS
Text/ Symbol
Digital Display
(Yes or
No)
Shortcut icon for summary information.
Tap the icon to check the input, output,
and battery status of the UPS. For more
information, please refer to 7.8 Power
Flow, Summary, System Status &
EMS.
Shortcut icon for system status. Tap the
icon to check the status of each power
module, parallel communication card,
system control card, and auxiliary power
card. For more information, please refer
to 7.8 Power Flow, Summary, System
Status & EMS.
Shortcut icon for EMS information. On
the EMS screen, you can check the
integrated status of each optional EMS
1000 (EnviroProbe) device connected
to the UPS (Green: Normal; Yellow:
integrated status is determined by the
most severe status among the device's
temperature (°C) status, humidity (%)
status, and the status of input contacts
DI1 ~ DI4. Please refer to 7.8 Power
Flow, Summary, System Status &
EMS.
ON/ OFF Button. For more information,
please refer to 7.3 ON/ OFF Button.
1. Bypass input status (Green: Normal;
2. Bypass input screen shortcut icon.
1. Main input status (Green: Normal;
2. Main input screen shortcut icon.
7-10
Description
Red: Abnormal or OFF).
Red: Abnormal or OFF).
