Delta Modulon DPH Series User Manual page 21

5. To see the wiring terminals shown in Figure 2-7 ~ Figure 2-9, please remove the twelve
screws from the two switch panels shown in Figure 2-6.
Upper Switch Panel
Screw × 12
Lower Switch Panel
N
AC Input
Terminals
Bypass Input
L3
Terminals
N
UPS Output
Terminals
L3
(Figure 2-7: Wiring Terminals_ AC Input, Bypass Input & UPS Output)
(Internal View with Two Front Doors Open)
INP UT SW
ITC H
BYP ASS
SW ITC H
MA NUA L
BYP ASS
SW ITC H
OU TPU T
SW ITC H
(Figure 2-6: Location of the Switch Panels and Screws)
(Internal View with Two Front Doors Open &
L3
L2
L1
L2
L1
L2
L1
2-9
Two Switch Panels Removal)
2 Introduction
