No.
1
2
3
4
5
6
7
Modulon DPH Series
Item
RESET
MODBUS
(Built-in MODUBS
card)
BMS
DISPLAY
EMS/ CONSOLE
(USB Port)
(Built-in SNMP card)
Press the RESET button once to restart the LCD.
1. Lets the UPS have MODBUS communication
function.
2. Connects to a user-supplied monitoring system.
Connects to the Delta battery management system
(optional). The BMS port application is only applicable
to the lead-acid batteries. Please refer to 7.10.4
Battery & Charging Setting.
Before shipment, the DISPLAY port has been
connected to the other display port shown in Figure 4-3
with the designated cable in Delta factory.
Connects to a user-supplied environmental monitoring
system or Delta EnviroProbe 1000 (optional).
There are two USB ports. Connects a user-supplied
logs.
1. Lets the UPS have network communication function.
2. Connects to a user-supplied monitoring system.
4-14
Function
