Delta Modulon DPH Series User Manual page 169

Button
Function
No. Icon/ Text
(Yes or
No)
90 %
16
5 mins
17
18
19
Load
30 %
20
Other icons on the touch panel are shown in the table below.
No.
1
2
3
4
Text/ Symbol
Digital Display
Display (Yes or
(Yes or No) No)
Icon
Goes to the top page.
Goes to the last page.
Moves up.
Moves down.
7-11
7 LCD Display & Settings
Description
1. Battery status (Green: Normal;
Flashing Green & Gray: Battery
Mode; Flashing Red & Gray: Battery
Not Connected).
2. Battery remaining capacity (%).
3. Battery remaining time (minutes).
4. Battery status screen shortcut icon.
Bypass static switch status (Green: ON;
Gray: Abnormal or OFF).
Waiting or OFF).
1. Inverter status (Green: Normal;
Gray: Waiting or OFF).
2. Inverter output screen shortcut icon.
1. Output status (Green: Normal; Gray:
No Output).
2. Load capacity (%).
3. UPS output screen shortcut icon.
Function
