1. If the status of the EMS 1000 (EnviroProbe) device (ID #) is OFF (gray) as shown in the
EMS
Off (gray)
Modulon DPH Series
Color
Item
(Status)
Green (Normal)
Yellow (Warning)
Red (Alarm)
Green (Normal)
Yellow (Warning)
Red (Alarm)
DI1
Green (None/
DI2
Information)
Yellow (Warning)
DI3
Red (Alarm)
DI4
UPS-1.1 MEASUREMENT SETUP
EMS
ID Title Temperature
0
EMS0
The color represents the status of Temperature/
Humidity based on the relevant settings. Please
refer to 7.10.10 EMS Setting.
When the detected Temperature/ Humidity
1. is lower than the value set for Warning, it
shows Green (Normal).
2. is higher than the value set for Warning but
lower than the value set for Alarm, it shows
Yellow (Warning).
3. is higher than the value set for Alarm, it shows
Red (Alarm).
4. has reached the value set for Alarm/
Warning, the status will recover from Alarm
to Warning/ from Warning to Normal
respectively only when the detected value has
been lowered to its corresponding Recovery
value.
status of each input contact.
2. The Title of input contacts DI1 ~ DI4, NO/
NC setting, and Event Type can be adjusted
according to your needs. Please refer to
7.10.10 EMS Setting.
