Power Module (Optional)

The power module is optional (not included in the package of the UPS). It is hot swappable
and each capacity is 50kVA/ 50kW. Please follow your UPS capacity to install the correct
number of power modules. Please refer to the table below.
UPS Capacity
Power Module Q'ty
Please see the table below for the power module's packing list.
No.
1
2
3
4

5.8.1 Power Module Installation

stated in 5.4 Fixing the UPS, continue with the following steps to install the power module
(optional) into the UPS.
200kVA/
200kW
4
LED Indicator
Handle
Switch
(Figure 5-32: Power Module (Optional))
1
Item
Power Module
Bracket Ear
M6 Screw
M4 Screw
300kVA/ 400kVA/
300kW 400kW
6
Fans
5-33
5 Installation and Wiring
500kVA/
500kW
8 10
Handle
2 3
× 4
× 2
Q'ty
1 PC
2 PCS
4 PCS
8 PCS
600kVA/
600kW
12
4
× 8
