Delta Modulon DPH Series User Manual page 145

UPS-1.1 MEASUREMENT
Power Flow
3
After selection of 'YES', the UPS will shut down the inverter, terminate each power
module's output and transfer to run in Standby mode. At this moment, the tri-color LED
indicator illuminates yellow and the following screen (Figure 6-50) appears. For the tri-
color LED indicator's location, please refer to Figure 2-11.
UPS-1.1 MEASUREMENT
Power Flow
POWER FLOW
Maintenance
Power Flow
Bypass
Bypass
Summary
Mains
System Status
90 %
5 mins
EMS
4
Switch OFF the Input Switch (Q1), Bypass Switch (Q2) and Output Switch (Q4).
5
6
About 3 minutes later, the UPS will shut down, and the LCD and tri-color LED indicator
7
Switch OFF every external battery cabinet's breaker (Q5).
SETUP MAINTENANCE
POWER OFF ?
Transfer to Bypass without Protection!
Yes
SETUP MAINTENANCE
(Figure 6-50: Standby Mode Screen)
6-35
2
LOG IN WARNING
User
No
2
LOG IN WARNING
User
Load
6 UPS Operation
10:15
Sep 25,2018
Battery
10:15
Sep 25,2018
Standby
0 %
