There are several optional accessories available for this DPH series UPS. Please refer to the table
below for the optional accessories and their descriptions.
No. Item
1 Dust Filter
2 Relay I/O Card
EMS 1000
3
(EnviroProbe)
Battery Cabinet
4 Temperature
Sensor Cable
Parallel Cable
5
(5-meter long)
Parallel Cable
6
(10-meter long)
Battery
7 Management
System (BMS)
Modulon DPH Series
Prevents dust from entering into the UPS to ensure UPS reliability and
to prolong product life.
Increases the quantity of dry contacts.
Monitors temperature, humidity and other connected monitoring
devices in a room environment. Connect the EMS 1000 (EnviroProbe)
to the UPS's EMS port located at the rear of the touch panel, and
the UPS will integrate the detected information of the EMS 1000
(EnviroProbe) and display relevant data on the LCD. See Figure
4-17 for the location of the EMS port. For more information about the
application of the EMS 1000 (EnviroProbe), please refer to 7.9.7 EMS
and 7.10.10 EMS Setting.
Detects the temperature of an external battery cabinet connected to
the UPS.
Connects the parallel UPSs.
Connects the parallel UPSs.
If you use the lead-acid batteries, it is recommended to install the
BMS to monitor (1) each battery's voltage, (2) each battery string's
voltage and charging/ discharging current, and (3) battery environment
temperature.
The BMS should be connected to the UPS's BMS port located at
the rear of the touch panel (see Figure 4-17). For relevant readings
and settings please refer to 7.9.6 Battery Status and 7.10.4 Battery
Charging Setting.
NOTE:
The number of the BMS that needs to be installed in the UPS
depends on how many external battery cabinets installed
with the lead-acid batteries are connected with the UPS. For
the installation of the BMS, please contact Delta customer
service.
Function
