Delta Modulon DPH Series User Manual page 103

3
Two people are required. One person holds the STS module's two pullers and opens
the two pullers outward
cabinet
to pull out the STS module from the UPS cabinet. When the STS module cannot be
pulled out any more, press the lock (see Figure 5-30) on the top of the STS module.
Now, each person holds one handle
continuously pull out the module from the UPS cabinet.
NOTE:
The person who holds the upper handle must hold the left indentation and the
person who holds the lower handle must hold the right indentation. For the
indentation location, please refer to Figure 5-30.
3
Handle
3
Handle
(Figure 5-29: Remove the STS Module from the UPS Cabinet)
. After that, the STS module can be pulled out from the UPS
1
. Next, each person holds one handle
2
(Internal View with Two Front Doors Open)
INP UT SW
ITC H
BYP ASS
SW ITC H
MA NU AL
BYP ASS
SW ITC H
OU TPU T
SW ITC H
2
3
and one indentation
3
4
5-31
5 Installation and Wiring
and two people work together
of the STS module to
4
1
Puller Puller
1
Puller
