(Internal View with Two Front Doors Open &
Two Switch Panels Removal)
N
AC Input
Terminals
L3
L2
L1
L3
L2
Bypass Input
L1
Terminals
N
UPS Output
Terminals
L3
L2
L1
(Figure 5-8: Wiring Terminals_ AC Input, Bypass Input & UPS Output)
(Internal View with Two Front Doors Open &
Two Switch Panels Removal)
Battery Input
N
Terminals
(Figure 5-9: Wiring Terminals_ Battery Input)
Modulon DPH Series
5-12
