UPS-1.1 MEASUREMENT
Power Flow
3
After selection of 'YES', the UPS will shut down the inverter and terminate each
power module's output. As there is no bypass output in Frequency Conversion mode,
all output will be terminated right after the inverter is shut down. Now, each power
module keeps charging the batteries, the tri-color LED indicator illuminates yellow and
the following screen appears (Figure 6-59). For the tri-color LED indicator's location,
please refer to Figure 2-11.
UPS-1.1 MEASUREMENT
Power Flow
POWER FLOW
Maintenance
Power Flow
Bypass
Bypass
Summary
Mains
System Status
90 %
5 mins
EMS
4
Switch OFF the Output Switch (Q4) and log in as an Administrator. For the Admini-
strator password, please contact service personnel. After login, ensure that you are in
the Administrator login status (see Figure 6-60).
SETUP MAINTENANCE
POWER OFF ?
Transfer to Bypass without Protection!
Yes
SETUP MAINTENANCE
(Figure 6-59: Standby Mode Screen)
6-41
LOG IN EVENT LOG
User
No
LOG IN EVENT LOG
User
Load
6 UPS Operation
10:15
Sep 25,2018
Standy
10:15
Sep 25,2018
Standby
0 %
