Delta Modulon DPH Series User Manual page 250

Model
UPS Capacity
Power Module Q'ty
Input
Output
Display
Interface
Battery
Environment
Operating Temperature
Modulon DPH Series
Nominal Voltage
Voltage Range
Current Harmonic
Distortion
Power Factor
Frequency Range
Voltage
Voltage Harmonic
Distortion
Power Factor
Frequency
Overload Capability
Standard
Online Mode
ECO Mode
Nominal Voltage
Charge Voltage
Protection of Battery
Deep Discharge
Operating Altitude
200kVA/ 300kVA/
200kW 300kW
4 6
176 ~ 276 Vac (full load)
10" Touch Panel
External battery temperature dry contact × 4,
External switch/ breaker status dry contact × 4,
Output dry contact × 6, Input dry contact × 4,
Parallel port × 4, USB type A × 2, USB type B × 1,
RS-232 port × 1, MODBUS port × 1, BMS (RJ45) × 1,
Ethernet × 1, SMART slot × 1, REPO × 1
± 240 Vdc (Default)
± 272 Vdc (adjustable from 204 Vdc to 312 Vdc)
1000 meters (without derating)
A1-2
DPH
400kVA/ 500kVA/
400kW 500kW
8 10
1
*
> 0.99
40 ~ 70 Hz
1
50/60 Hz
up to 96.5%
99%
Yes
0 ~ 40°C
600kVA/
600kW
12
