Delta Modulon DPH Series User Manual page 100

2
Two people are required. Each person holds one handle
of the STS module and two people work together to insert the STS module into the
designated slot
pullers inward in order to push the module into the end of the UPS cabinet until it
snaps into place. Now, the two pullers are in the closed status.
Modulon DPH Series
(STS Module Left Side View)
. After that, one person holds the two pullers
3
NOTE:
The person who holds the upper handle must hold the left indentation and the
person who holds the lower handle must hold the right indentation. For the
indentation location, please refer to Figure 5-21.
Puller
Open Status
Puller
5-28
and one indentation
1
and push the two
4
2
