5 Installation and Wiring
(Internal View with Two Front Doors Open &
Two Switch Panels Removal)
Grounding
Terminals
( & )
(Figure 5-10: Wiring Terminals_ Grounding)
3
For top wiring, please remove the three top covers shown in Figure 5-11 for cable
entry. Each top cover has two screws.
(Internal View with Two Front Doors Open &
Two Switch Panels Removal)
Top Cover × 3
(Each with
2 Screws)
(Figure 5-11: Location of the Top Covers)
5-13
