Parameter Lists
Parameter # Parameter description
15-4* Drive Identification
15-40 FC Type
15-41 Power Section
15-42 Voltage
15-43 Software Version
15-44 Ordered TypeCode
15-45 Actual Typecode String
15-46 Drive Ordering No
15-48 LCP Id No
15-49 SW ID Control Card
15-50 SW ID Power Card
15-51 Drive Serial Number
15-52 OEM Information
15-53 Power Card Serial Number
15-57 File Version
15-59 Filename
15-6* Option Ident
15-60 Option Mounted
15-61 Option SW Version
15-70 Option in Slot A
15-71 Slot A Option SW Version
15-9* Parameter Info
15-92 Defined Parameters
15-97 Application Type
15-98 Drive Identification
15-99 Parameter Metadata

5.2.16 16-** Data Readouts

Parameter # Parameter description
16-0* General Status
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference [%]
16-03 Status Word
16-05 Main Actual Value [%]
16-09 Custom Readout
16-1* Motor Status
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
16-13 Frequency
16-14 Motor current
16-15 Frequency [%]
16-16 Torque [Nm]
16-17 Speed [RPM]
16-18 Motor Thermal
16-20 Motor Angle
16-22 Torque [%]
MG07C302
Programming Guide
Default value 4 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A All set-ups
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
Size Related All set-ups
Size Related All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
Default value 4 set-up
0 N/A 1 set-up
0 ReferenceFeed-
backUnit 1 set-up
0 % 1 set-up
0 N/A 1 set-up
0 % 1 set-up
0 CustomRea-
doutUnit 1 set-up
0 kW 1 set-up
0 hp 1 set-up
0 V 1 set-up
0 Hz 1 set-up
0 A 1 set-up
0 % 1 set-up
0 Nm All set-ups
0 RPM All set-ups
0 % 1 set-up
0 N/A All set-ups
0 % All set-ups
Danfoss A/S © 07/2016 All rights reserved.
Change during Conversion
operation index
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
TRUE 0
TRUE 0
FALSE 0
FALSE 0
Change during Conversion
operation index
TRUE 0
TRUE -3
TRUE -1
TRUE 0
TRUE -2
TRUE -2
TRUE -3
TRUE -3
TRUE -1
TRUE -1
TRUE -2
TRUE -1
FALSE -1
FALSE 0
TRUE 0
TRUE 0
FALSE 0
Type
VisStr[7]
VisStr[20]
VisStr[20]
VisStr[20]
VisStr[41]
VisStr[40]
VisStr[9]
VisStr[21]
5 5
VisStr[21]
VisStr[21]
VisStr[13]
VisStr[40]
VisStr[21]
Uint8
VisStr[16]
VisStr[30]
VisStr[20]
VisStr[30]
VisStr[20]
Uint16
Uint32
VisStr[56]
Uint16
Type
Uint16
Int32
Int16
Uint16
Int16
Int32
Uint32
Uint32
Uint32
Uint32
Uint16
Uint16
Int32
Int32
Uint8
Uint16
Int16
117
