Parameter Descriptions

4.17 Parameters: 18-** Data Readouts 2

18-90 Process PID Error
Range: Function:
0 % [-200 - 200 %] Give the present error value used by the
*
process PID controller.
18-91 Process PID Output
Range: Function:
0 % [-200 - 200 %] Give the present raw output value from
*
the process PID controller.
18-92 Process PID Clamped Output
Range: Function:
0 % [-200 - 200 %] Give the present output value from the
*
process PID controller after the clamp
limits have been observed.
18-93 Process PID Gain Scaled Output
Range: Function:
0 % [-200 - Give the present output value from the
*
200 %] process PID controller after the clamp
limits have been observed, and the
resulting value has been gain scaled.
MG07C302
Programming Guide

4.18 Parameters: 21-** Ext. Closed Loop

21-09 Extended PID Enable
Select the extended CL PID controller that is to be autotuned.
Option:
[0]
*
[1]
21-11 Ext. 1 Minimum Reference
Range:
0 ExtPID1Unit
21-12 Ext. 1 Maximum Reference
Range:
100
ExtPID1Unit
21-13 Ext. 1 Reference Source
This parameter defines which input on the frequency converter
should be treated as the source of the reference signal.
Option:
[0]
*
[1]
[2]
[7]
[8]
21-14 Ext. 1 Feedback Source
This parameter defines which input on the frequency converter
should be treated as the source of the feedback signal.
Option:
[0]
*
[1]
[2]
[3]
[4]
21-15 Ext. 1 Setpoint
Range:
0 ExtPID1Unit
21-17 Ext. 1 Reference [Unit]
Range:
0 ExtPID1Unit
Danfoss A/S © 07/2016 All rights reserved.
Disabled
Enabled Ext CL1 PID
Function:
[ -999999.999 - This parameter sets the
*
999999.999 minimum value that can be
ExtPID1Unit] obtained by the sum
setpoint and reference.
Function:
[ -999999.999 - This parameter sets the
999999.999 maximum value that can
ExtPID1Unit] be obtained by the sum of
the setpoint and reference.
Function:
No function
Analog Input 53
Analog Input 54
Frequency input 29
Frequency input 33
Function:
No function
Analog Input 53
Analog Input 54
Frequency input 29
Frequency input 33
Function:
[-999999.999 - This parameter is used as the
*
999999.999 reference for comparing
ExtPID1Unit] feedback values. The setpoint
can be offset with digital,
analog, or bus references.
Function:
[-999999.999 - Return the resulting
*
999999.999 ExtPID1Unit] reference value.
Function:
4 4
