Parameter Descriptions

4.2 Parameters: 1-** Load and Motor

1-00 Configuration Mode
Option: Function:
Select the application control principle to be
used when a remote reference (that is analog
input or fieldbus) is active.
[0] Open Loop Enable speed control (without feedback signal
from motor) with automatic slip compen-
*
sation for almost constant speed at varying
loads. Compensations are active, but can be
disabled in parameter group 1-0* Load and
Motor.
[1] Speed Enable speed closed-loop control with
closed loop feedback. For increased speed accuracy,
provide a feedback signal and set the speed
PID control. The speed control parameters are
set in parameter group 7-0* Speed PID Control.
[2] Torque Enable torque closed-loop control with speed
closed loop
feedback. Only possible when option [1] VVC
is selected in parameter 1-01 Motor Control
Principle.
[3] Process Enable the use of process control in the
Closed Loop frequency converter. The process control
parameters are set in parameter groups 7-2*
Process Ctrl. Feedback and 7-3* Process PID Ctrl.
[4] Torque
open loop
[7] Extended
PID Speed
OL
1-01 Motor Control Principle
Option: Function:
NOTICE
[0] U/f
When running U/f, control slip and load
compensations are not included.
Used for parallel-connected motors and/or special
motor applications. Set the U/f settings in
parameter 1-55 U/f Characteristic - U and
parameter 1-56 U/f Characteristic - F.
NOTICE
[1] VVC+
*
When parameter 1-10 Motor Construction is
set to PM-enabled options, only VVC
is available.
Normal running mode, including slip and load
compensations.
MG07C302
Programming Guide
1-03 Torque Characteristics
Option:
[0] Constant torque
*
[1] Variable Torque
[2] Auto Energy Optim. CT
1-06 Clockwise Direction
Option:
+
[0] Normal The motor shaft turns in clockwise direction when
*
[1] Inverse The motor shaft turns in counterclockwise
1-08 Motor Control Bandwidth
Option:
[0] High
[1] Medium
[2] Low
*
[3] Adaptive 1 Optimized for smooth steady-state operation,
[4] Adaptive 2 Focus on low-inductance PM motors. This
1-10 Motor Construction
Option:
[0] Asynchron
*
[1] PM, non-
salient SPM
+
option
[2] PM, salient
IPM, non Sat.
[3] PM, salient
IPM, Sat.
Danfoss A/S © 07/2016 All rights reserved.
Function:
Select the torque characteristic
required. VT and AEO are both
energy-saving operations.
Function:
NOTICE
This parameter cannot be adjusted while
the motor is running.
This parameter defines the term clockwise
corresponding to the LCP direction arrow. Used for
easy change of direction of shaft rotation without
swapping motor wires.
frequency converter is connected U⇒U; V⇒V; and
W⇒W to motor.
direction when frequency converter is connected
U⇒U; V⇒V; and W⇒W to motor.
Function:
Suitable for high dynamic response.
Suitable for smooth steady-state operation.
Suitable for smooth steady-state operation with
lowest dynamic response.
with extra active damping.
option is an alternative to [3] Adaptive 1.
Function:
For asynchronous motors.
For permanent magnet (PM) motors with
surface-mounted (non-salient) magnets.
Refer to parameter 1-14 Damping Gain to
parameter 1-17 Voltage filter time const. for
details about optimizing the motor
operation.
For permanent magnet (PM) motors with
interior (salient) magnets, without
inductance saturation control.
For permanent magnet (PM) motors with
interior (salient) magnets, with inductance
saturation control.
