Parameter Descriptions
Preset ref. bit
Preset ref. 0
Preset ref. 1
Preset ref. 2
Preset ref. 3
Preset ref. 4
Preset ref. 5
Preset ref. 6
Preset ref. 7
Table 4.1 Preset Ref. Bit
[19] Freeze Freeze the actual reference, which is now the point
ref of enable/condition for [21] Speed up and [22]
Speed down to be used. If [21] Speed up or [22]
Speed down is used, the speed change always
follows ramp 2 (parameter 3-51 Ramp 2 Ramp Up
Time and parameter 3-52 Ramp 2 Ramp Down Time)
in the range 0–parameter 3-03 Maximum Reference.
NOTICE
[20] Freeze
output
When [20] Freeze output is active, the
frequency converter cannot be stopped by
setting the signal on [8] Start to low. Stop
the frequency converter via a terminal
programmed for [2] Coasting inverse or [3]
Coast and reset, inverse.
Freeze the actual motor frequency (Hz), which is
now the point of enable/condition for [21] Speed
up and [22] Speed down to be used. If [21] Speed up
or [22] Speed down is used, the speed change
always follows ramp 2 (parameter 3-51 Ramp 2
Ramp Up Time and parameter 3-52 Ramp 2 Ramp
Down Time) in the range 0–parameter 1-23 Motor
Frequency.
[21] Speed Select [21] Speed up and [22] Speed down if digital
up control of the up/down speed is needed (motor
potentiometer). Activate this function by selecting
either [19] Freeze reference or [20] Freeze output.
When speed up/down is activated for less than 400
ms, the resulting reference is increased/decreased
by 0.1%. If speed up/down is activated for more
than 400 ms, the resulting reference follows the
setting in ramping up/down parameter 3-x1/3-x2.
Unchanged speed
Reduced by %-value
Increased by %-value
Reduced by %-value
Table 4.2 Shut Down/Catch Up
[22] Speed Same as [21] Speed up.
down
[23] Set-up Select [23] Set-up select bit 0 or [1] Set-up select
select bit bit 1 to select 1 of the 2 set-ups. Set
0 parameter 0-10 Active Set-up to [9] Multi Set-up.
MG07C302
Programming Guide
2 1 0
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
Shut down Catch up
0 0
1 0
0 1
1 1
