Danfoss VLT Midi Drive FC 280 Programming Manual page 78

Parameter Descriptions
13-02 Stop Event
Select the condition (true or false) which deactivates the smart
logic controller.
Option:
[4]
[7]
[8]
[9]
4 4
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[34]
[35]
[36]
[39]
[40]
*
[42]
[50]
[51]
[60]
[61]
[70]
[71]
[72]
[73]
[74]
[83]
13-03 Reset SLC
Option:
[0] Do not reset
*
SLC
[1] Reset SLC
76
VLT
On reference
Out of current range
Below I low
Above I high
Thermal warning
Mains out of range
Reversing
Warning
Alarm (trip)
Alarm (trip lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
SL Time-out 0
SL Time-out 1
SL Time-out 2
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29
Start command
Drive stopped
Auto Reset Trip
Comparator 4
Comparator 5
Logic rule 4
Logic rule 5
SL Time-out 3
SL Time-out 4
SL Time-out 5
SL Time-out 6
SL Time-out 7
Broken Belt
Function:
Retain programmed settings in parameter
group 13-** Smart Logic.
Reset all parameters in parameter group 13-
** Smart Logic to default settings.
Danfoss A/S © 07/2016 All rights reserved.
®
Midi Drive FC 280
13-10 Comparator Operand
Select the variable to be monitored by the comparator. This is an
array parameter containing comparators 0 to 5.
Function: Option:
[0]
*
[1]
[2]
[3]
[4]
[6]
[7]
[12]
[13]
[18]
[19]
[20]
[30]
[31]
13-11 Comparator Operator
Option:
[0] Less Than (<)
[1] Approx.Equal
(~)
*
[2] Greater Than
(>)
13-12 Comparator Value
Range:
0 [-9999 -
*
9999 ]
Function:
Disabled
Reference %
Feedback %
Motor speed
Motor Current
Motor power
Motor voltage
Analog input AI53
Analog input AI54
Pulse input FI29
Pulse input FI33
Alarm number
Counter A
Counter B
Function:
Select the operator to be used in the
comparison. This is an array parameter
containing comparator operators 0–5.
The result of the evaluation is true, when
the variable selected in
parameter 13-10 Comparator Operand is
smaller than the fixed value in
parameter 13-12 Comparator Value. The result
is false, if the variable selected in
parameter 13-10 Comparator Operand is
greater than the fixed value in
parameter 13-12 Comparator Value.
The result of the evaluation is true, when
the variable speed selected in
parameter 13-10 Comparator Operand is
approximately equal to the fixed value in
parameter 13-12 Comparator Value.
Inverse logic of [0] Less Than (<).
Function:
Enter the trigger level for the variable that is
monitored by this comparator. This is an
array parameter containing comparator
values 0–5.
MG07C302
