Parameter Descriptions

4.7 Parameters: 6-** Analog In/Out

6-00 Live Zero Timeout Time
Range:
10 s [1 - 99 s]
*
6-01 Live Zero Timeout Function
Option:
4 4
[0] Off
*
[1] Freeze
output
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and
trip
Par 6-xx
High Ref./
Feedb. Value'
Par 6-xx
Low Ref./
Feedb. Value'
Illustration 4.13 Timeout Function
6-10 Terminal 53 Low Voltage
Range:
0.07 V [0 - 10
*
V]
62
Function:
Enter the timeout time.
Function:
Select the timeout function. The function set
in parameter 6-01 Live Zero Timeout Function is
activated if the input signal on terminal 53 or
54 is below 50% of the value in
parameter 6-10 Terminal 53 Low Voltage,
parameter 6-20 Terminal 54 Low Voltage, or
parameter 6-22 Terminal 54 Low Current for a
time period defined in parameter 6-00 Live
Zero Timeout Time.
Ref./Feedback
1500
1200
900
600
300
150
1 V 5 V
Par 6-xx
'Low Voltage'or
'Low Current'
Par 6-xx
'High Voltage'or
'High Current'
Function:
Enter the voltage (V) that corresponds to
parameter 6-14 Terminal 53 Low Ref./Feedb.
Value. To activate parameter 6-01 Live Zero
Timeout Function, set the value at >1 V.
Danfoss A/S © 07/2016 All rights reserved.
®
VLT Midi Drive FC 280
6-11 Terminal 53 High Voltage
Range:
10 V
*
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0 [-4999 -
*
4999 ]
6-15 Terminal 53 High Ref./Feedb. Value
Range:
Size
related
*
6-16 Terminal 53 Filter Time Constant
Range:
0.01 s
*
6-18 Terminal 53 Digital Input
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
10 V [V]
[6]
Analog input
[8]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
Function:
[0 - 10 V] Enter the voltage (V) that corresponds to the
high reference value (set in
parameter 6-15 Terminal 53 High Ref./Feedb.
Value).
Function:
Enter the reference or feedback value that
corresponds to the voltage or current set in
parameter 6-10 Terminal 53 Low Voltage.
Function:
[-4999 - Enter the reference or feedback value
4999 ] that corresponds to the voltage or
current set in parameter 6-11 Terminal
53 High Voltage.
Function:
[0.01 - 10 Enter the time constant. This constant is a
s] first-order digital low-pass filter time
constant for suppressing electrical noise in
terminal 53. A high time constant value
improves dampening, but also increases the
time delay through the filter.
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC-brake inverse
Stop inverse
Start
Reversing
Start reversing
Enable start forward
Enable start reverse
Jog
Preset reference on
Preset ref bit 0
Preset ref bit 1
Preset ref bit 2
Freeze reference
Freeze output
Speed up
Speed down
Set-up select bit 0
Set-up select bit 1
Function:
