Parameter Descriptions
13-52 SL Controller Action
Option:
[14] Select preset
ref 4
4 4
[15] Select preset
ref 5
[16] Select preset
ref 6
[17] Select preset
ref 7
[18] Select ramp
1
[19] Select ramp
2
[22] Run
[23] Run reverse
[24] Stop
[25] Qstop
[26] DC Brake
[27] Coast
[28] Freeze
output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital
out A low
[33] Set digital
out B low
[34] Set digital
out C low
80
®
VLT
Function:
preset reference commands coming from
either the digital inputs, or via a fieldbus.
Select preset reference 4. If the active preset
reference is changed, it merges with other
preset reference commands coming from
either the digital inputs, or via a fieldbus.
Select preset reference 5. If the active preset
reference is changed, it merges with other
preset reference commands coming from
either the digital inputs, or via a fieldbus.
Select preset reference 6. If the active preset
reference is changed, it merges with other
preset reference commands coming from
either the digital inputs, or via a fieldbus.
Select preset reference 7. If the active preset
reference is changed, it merges with other
preset reference commands coming from
either the digital inputs, or via a fieldbus.
Select ramp 1.
Select ramp 2.
Issue a start command to the frequency
converter.
Issue a start reverse command to the
frequency converter.
Issue a stop command to the frequency
converter.
Issue a quick stop command to the
frequency converter.
Issue a DC-brake command to the frequency
converter.
The frequency converter coasts immediately.
All stop commands including the coast
command stop the SLC.
Freeze the output of the frequency
converter.
See parameter 13-20 SL Controller Timer for
further description.
See parameter 13-20 SL Controller Timer for
further description.
See parameter 13-20 SL Controller Timer for
further description.
Any output with SL output A is low.
Any output with SL output B is low.
Any output with SL output C is low.
Danfoss A/S © 07/2016 All rights reserved.
Midi Drive FC 280
13-52 SL Controller Action
Option:
[35] Set digital
out D low
[38] Set digital
out A high
[39] Set digital
out B high
[40] Set digital
out C high
[41] Set digital
out D high
[60] Reset
Counter A
[61] Reset
Counter B
[70] Start Timer 3 See parameter 13-20 SL Controller Timer for
[71] Start Timer 4 See parameter 13-20 SL Controller Timer for
[72] Start Timer 5 See parameter 13-20 SL Controller Timer for
[73] Start Timer 6 See parameter 13-20 SL Controller Timer for
[74] Start Timer 7 See parameter 13-20 SL Controller Timer for
Function:
Any output with SL output D is low.
Any output with SL output A is high.
Any output with SL output B is high.
Any output with SL output C is high.
Any output with SL output D is high.
Reset counter A to 0.
Reset counter B to 0.
further description.
further description.
further description.
further description.
further description.
