Parameter Descriptions

4.10 Parameters: 9-** PROFIdrive

For PROFIBUS parameter descriptions, see the VLT
Drive FC 280 PROFIBUS DP Programming Guide.
For PROFINET parameter descriptions, see the VLT
Drive FC 280 PROFINET Programming Guide.

4.11 Parameters: 10-** CAN Fieldbus

For CAN Fieldbus parameter descriptions, see the VLT
Drive FC 280 CANopen Programming Guide.

4.12 Parameters: 12-** Ethernet

For Ethernet parameter descriptions, see the VLT
Drive FC 280 EtherNet/IP Programming Guide and VLT
Drive FC 280 PROFINET Programming Guide.
MG07C302
Programming Guide

4.13 Parameters: 13-** Smart Logic Control

®
Midi
13-00 SL Controller Mode
Option:
[0]
*
®
Midi
[1]
13-01 Start Event
Select the condition (true or false) which activates the smart
®
Midi
logic controller.
Option:
[0]
[1]
®
Midi
[2]
®
Midi
[3]
[4]
[7]
[8]
[9]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[33]
[34]
[35]
[36]
[39]
*
[40]
[42]
[50]
[51]
[60]
[61]
[83]
13-02 Stop Event
Select the condition (true or false) which deactivates the smart
logic controller.
Option:
[0]
[1]
[2]
[3]
Danfoss A/S © 07/2016 All rights reserved.
Function:
Off Disable the smart logic controller.
On Enable the smart logic controller.
False
True
Running
In range
On reference
Out of current range
Below I low
Above I high
Thermal warning
Mains out of range
Reversing
Warning
Alarm (trip)
Alarm (trip lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29
Start command
Drive stopped
Auto Reset Trip
Comparator 4
Comparator 5
Logic rule 4
Logic rule 5
Broken Belt
False
True
Running
In range
4 4
Function:
Function:
75
