Parameter Descriptions
13-20 SL Controller Timer
Range: Function:
0 s [0 - 3600 Enter the value to define the duration of the
*
s] false output from the programmed timer. A
timer is only false if it is started by an action
(for example [29] Start timer 1) and until the
given timer value has elapsed.
13-40 Logic Rule Boolean 1
Option: Function:
Select the 1
input for the selected logic rule. See
parameter 13-01 Start Event ([0]–[61])
and parameter 13-02 Stop Event ([70]–
[74]) for further description.
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
