Parameter Descriptions
4.9 Parameters: 8-** Communications and
Options
8-01 Control Site
Option: Function:
The setting in this parameter overrides
the settings in parameter 8-50 Coasting
Select to parameter 8-58 Profidrive OFF3
Select.
[0] Digital and Control by using both digital input and
*
ctrl.word control word.
[1] Digital only Control by using digital inputs only.
[2] Controlword Control by using control word only.
only
8-02 Control Source
Option: Function:
Select the source of the control word.
NOTICE
This parameter cannot be adjusted while
the motor is running.
[0] None
[1] FC Port
[2] FC USB
[3] Option A
8-03 Control Timeout Time
Range: Function:
1 s [0.1 - Enter the maximum time expected to pass
*
6000 s] between the reception of 2 consecutive
telegrams. If this time is exceeded, it indicates
that the serial communication has stopped. The
function that is selected in
parameter 8-04 Control Timeout Function is then
carried out.
8-04 Control Timeout Function
Option: Function:
[0] Off Select the timeout function. The timeout
*
function is activated when the control word
fails to be updated within the time period
specified in parameter 8-03 Control Timeout
Time.
[1] Freeze output
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and trip
MG07C302
Programming Guide
8-07 Diagnosis Trigger
Option:
[0] Disable
*
[1] Trigger on
alarms
[2] Trigger
alarm/warn.
8-10 Control Word Profile
Select the interpretation of the control and status words
corresponding to the installed fieldbus.
Option:
[0]
*
[1]
[5]
[7]
8-14 Configurable Control Word CTW
The control word has 16 bits (0–15). Bits 10 and 12–15 are
configurable.
Option:
[0]
[1]
*
[2]
[4]
[5]
[6]
8-19 Product Code
Range:
Size
related
*
8-30 Protocol
Option:
[0] FC
*
[2] Modbus RTU Communication according to the Modbus
8-31 Address
Range:
1 [ 0 - 247 ] Enter the address for the RS485 port. Valid range:
*
Danfoss A/S © 07/2016 All rights reserved.
Function:
Send no extended diagnosis data (EDD).
Send EDD upon alarms.
Send EDD upon alarms or warnings in
parameter 16-90 Alarm Word,
parameter 9-53 Profibus Warning Word, or
parameter 16-92 Warning Word.
FC profile
PROFIdrive profile
ODVA
CANopen DSP 402
None
Profile default
CTW Valid, active low
PID error inverse
PID reset I part
PID enable
Function:
[0 - Select 0 to read out the actual
2147483647] fieldbus product code according
to the mounted fieldbus option.
Select 1 to read out the actual
vendor ID.
Function:
Select the protocol for the integrated RS485
port.
Communication according to the FC protocol.
RTU protocol.
Function:
1–126 for FC-bus, or 1–247 for Modbus.
4
