9-** Profidrive - Danfoss VLT Midi Drive FC 280 Programming Manual

Parameter Lists
Parameter # Parameter description
8-57 Profidrive OFF2 Select
8-58 Profidrive OFF3 Select
8-7* BACnet
8-79 Protocol Firmware version
8-8* FC Port Diagnostics
8-80 Bus Message Count
8-81 Bus Error Count
8-82 Slave Messages Rcvd
8-83 Slave Error Count
8-84 Slave Messages Sent
8-85 Slave Timeout Errors
8-88 Reset FC port Diagnostics
8-9* Bus Feedback
8-90 Bus Jog 1 Speed
8-91 Bus Jog 2 Speed

5.2.10 9-** PROFIdrive

Parameter # Parameter description
9-00 Setpoint
9-07 Actual Value
9-15 PCD Write Configuration
9-16 PCD Read Configuration
9-18 Node Address
9-19 Drive Unit System Number
9-22 Telegram Selection
9-23 Parameters for Signals
9-27 Parameter Edit
9-28 Process Control
9-44 Fault Message Counter
9-45 Fault Code
9-47 Fault Number
9-52 Fault Situation Counter
9-53 Profibus Warning Word
9-63 Actual Baud Rate
9-64 Device Identification
9-65 Profile Number
9-67 Control Word 1
9-68 Status Word 1
9-70 Edit Set-up
9-71 Profibus Save Data Values
9-72 ProfibusDriveReset
9-75 DO Identification
9-80 Defined Parameters (1)
9-81 Defined Parameters (2)
9-82 Defined Parameters (3)
9-83 Defined Parameters (4)
9-84 Defined Parameters (5)
9-85 Defined Parameters (6)
MG07C302
Programming Guide
Default value 4 set-up
[3] Logic OR All set-ups
[3] Logic OR All set-ups
Size Related 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
[0] Do not reset 1 set-up
100 RPM All set-ups
200 RPM All set-ups
Default value 4 set-up
0 N/A All set-ups
0 N/A All set-ups
Size Related 1 set-up
Size Related 1 set-up
126 N/A 1 set-up
1037 N/A All set-ups
[100] None 1 set-up
0 All set-ups
[1] Enabled 1 set-up
[1] Enable cyclic
master 1 set-up
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
[255] No baudrate
found All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
[9] Active Set-up 1 set-up
[0] Off All set-ups
[0] No action 1 set-up
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
