Parameter Descriptions
3-16 Reference 2 Source
Option: Function:
[20] Digital pot.meter
[32] Bus PCD
3-17 Reference 3 Source
Option: Function:
Select the reference input to be used
for the first reference signal.
Parameter 3-15 Reference 1 Source,
parameter 3-16 Reference 2 Source, and
parameter 3-17 Reference 3 Source
define up to 3 different reference
signals. The sum of these reference
signals defines the actual reference.
[0] No function
[1] Analog Input 53
[2] Analog Input 54
[7] Frequency input
29
[8] Frequency input
33
[11] Local bus
*
reference
[20] Digital pot.meter
[32] Bus PCD
3-18 Relative Scaling Reference Resource
Option: Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Select a variable value to be added to the
fixed value (defined in
parameter 3-14 Preset Relative Reference).
The sum of the fixed and variable values
(labeled Y in Illustration 4.5) is multiplied
by the actual reference (labeled X in
Illustration 4.5). This product is then
added to the actual reference (X+X*Y/100)
to give the resulting actual reference.
Y
X
Illustration 4.5 Resulting Actual
Reference
[0] No function
*
[1] Analog Input 53
[2] Analog Input 54
[7] Frequency input
29
MG07C302
Programming Guide
Resulting
Relative Z
actual
Z=X+X*Y/100
reference
