Introduction

1 Introduction

1.1 How to Read This Programming Guide

1.1.1 Purpose of the Manual
This programming guide provides information about
controlling the frequency converter, accessing parameters,
programming, and troubleshooting.
The programming guide is intended for use by qualified
personnel who are familiar with the VLT
280 frequency converter.
Read the instructions before programming and follow the
procedures in this manual.
®
VLT is a registered trademark.

1.1.2 Additional Resources

Additional resources include:
•
®
VLT Midi Drive FC 280 Operating Guide, provides
the necessary information for getting the
frequency converter up and running.
•
®
VLT Midi Drive FC 280 Design Guide, provides
detailed technical information about the
frequency converter, customer design, and
applications.
Contact the local Danfoss supplier or go to
drives.danfoss.com/knowledge-center/technical-documen-
tation/ to download the documentations.

1.1.3 Document and Software Version

This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version and the corresponding software
version.
Edition Remarks
MG07C3 Update due to new software
version release.
Table 1.1 Document and Software Version
MG07C302
Programming Guide
°C
°F
AC
AEO
ACP
AWG
AMA
DC
®
Midi Drive FC
EEPROM
EMC
EMI
ESD
ETR
f
M,N
FC
IGBT
IP
I
LIM
I
INV
I
M,N
I
VLT,MAX
I
VLT,N
L
d
L
q
LCP
LED
MCP
N.A.
NEMA
P
M,N
PCB
PE
PELV
Software
PWM
version
R
1.2
s
Regen
RPM
RFI
SCR
SMPS
T
LIM
U
M,N
X
h
Table 1.2 Abbreviations
