Parameter Descriptions
13-44 Logic Rule Boolean 3
Option: Function:
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken Belt
13-51 SL Controller Event
Option: Function:
Select the 3
input for the selected logic rule. See
parameter 13-40 Logic Rule Boolean 1,
parameter 13-41 Logic Rule Operator 1,
parameter 13-42 Logic Rule Boolean 2,
and the boolean input. See
parameter 13-01 Start Event ([0]–[61])
and parameter 13-02 Stop Event ([70]–
[74]) for further description.
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
MG07C302
Programming Guide
rd boolean (true or false)
Danfoss A/S © 07/2016 All rights reserved.
13-51 SL Controller Event
Option: Function:
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken Belt
13-52 SL Controller Action
Option: Function:
[0] Disabled Select the action corresponding to the SLC
*
event. Actions are executed when the
corresponding event (defined in
parameter 13-51 SL Controller Event) is
evaluated as true.
[1] No action
[2] Select set-up Change the active set-up
1 (parameter 0-10 Active Set-up) to 1. If the set-
up is changed, it merges with other set-up
commands coming from either the digital
inputs, or via a fieldbus.
[3] Select set-up Change the active set-up
2 (parameter 0-10 Active Set-up) to 2. If the set-
up is changed, it merges with other set-up
commands coming from either the digital
inputs, or via a fieldbus.
[4] Select set-up Change the active set-up
3 (parameter 0-10 Active Set-up) to 3. If the set-
up is changed, it merges with other set-up
commands coming from either the digital
inputs, or via a fieldbus.
[5] Select set-up Change the active set-up
4 (parameter 0-10 Active Set-up) to 4. If the set-
up is changed, it merges with other set-up
commands coming from either the digital
inputs, or via a fieldbus.
[10] Select preset Select preset reference 0. If the active preset
ref 0 reference is changed, it merges with other
preset reference commands coming from
either the digital inputs or via a fieldbus.
[11] Select preset Select preset reference 1. If the active preset
ref 1 reference is changed, it merges with other
preset reference commands coming from
either the digital inputs, or via a fieldbus.
[12] Select preset Select preset reference 2. If the active preset
ref 2 reference is changed, it merges with other
preset reference commands coming from
either the digital inputs, or via a fieldbus.
[13] Select preset Select preset reference 3. If the active preset
ref 3 reference is changed, it merges with other
4 4
