Parameter Descriptions
13-42 Logic Rule Boolean 2
Option:
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
4 4
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken Belt
13-43 Logic Rule Operator 2
Option:
[0] Disabled
*
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
78
®
VLT
Function:
Function:
Select the 2 nd logical operator to be used on
the boolean input calculated in
parameter 13-40 Logic Rule Boolean 1,
parameter 13-41 Logic Rule Operator 1, and
parameter 13-42 Logic Rule Boolean 2, and
the boolean input coming from
parameter 13-42 Logic Rule Boolean 2.
Parameter 13-42 Logic Rule Boolean 2
signifies the boolean input of
parameter 13-44 Logic Rule Boolean 3.
Parameter 13-40 Logic Rule Boolean 1, and
parameter 13-42 Logic Rule Boolean 2 signify
the boolean input calculated in
parameter 13-40 Logic Rule Boolean 1,
parameter 13-41 Logic Rule Operator 1, and
parameter 13-42 Logic Rule Boolean 2.
Ignore parameter 13-44 Logic Rule Boolean 3.
Danfoss A/S © 07/2016 All rights reserved.
Midi Drive FC 280
13-43 Logic Rule Operator 2
Option:
[6] NOT OR
[7] NOT AND
NOT
[8] NOT OR NOT
13-44 Logic Rule Boolean 3
Option:
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
Function:
Function:
rd
Select the 3 boolean (true or false)
input for the selected logic rule. See
parameter 13-40 Logic Rule Boolean 1,
parameter 13-41 Logic Rule Operator 1,
and parameter 13-42 Logic Rule
Boolean 2, and the boolean input.
See parameter 13-01 Start Event ([0]–
[61]), and parameter 13-02 Stop Event
([70]–[74]) for further description.
