Parameter Descriptions
8-32 Baud Rate
Option:
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
*
[3] 19200 Baud
[4] 38400 Baud
4 4
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
8-33 Parity / Stop Bits
Parity and stop bits for the protocol using the FC port. For some
of the protocols, not all options are available.
Option:
[0]
[1]
[2]
[3]
8-35 Minimum Response Delay
Range:
0.01 s [ 0.0010 - 0.5
*
s]
8-36 Maximum Response Delay
Range:
Size related
*
s]
8-37 Maximum Inter-char delay
Range:
0.025 s [0.025 - 0.025
*
s]
8-42 PCD Write Configuration
Select the parameters to be assigned to the PCD's telegrams. The
number of available PCDs depends on the telegram type. The
values in the PCDs are then written to the selected parameters
as data values.
Option:
[0]
[1]
[2]
[3]
[4]
72
Function:
Select the baud rate for the RS485 port.
Function:
Even Parity, 1 Stop Bit
Odd Parity, 1 Stop Bit
No Parity, 1 Stop Bit
No Parity, 2 Stop Bits
Function:
Specify the minimum delay time
between receiving a request and
transmitting a response. This is used for
overcoming modem turn-around
delays.
Function:
[ 0.1 - 10.0 Specify the maximum allowed delay
time between receiving a request and
transmitting the response. If this time
is exceeded, no response is returned.
Function:
Specify the maximum delay time
between 2 characters in a message.
Exceeding this delay time causes the
message to be discarded.
None
[302] Minimum Reference
[303] Maximum Reference
[341] Ramp 1 Ramp up time
[342] Ramp 1 Ramp down time
Danfoss A/S © 07/2016 All rights reserved.
®
VLT Midi Drive FC 280
8-42 PCD Write Configuration
Select the parameters to be assigned to the PCD's telegrams. The
number of available PCDs depends on the telegram type. The
values in the PCDs are then written to the selected parameters
as data values.
Option:
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
8-43 PCD Read Configuration
Select the parameters to be assigned to the PCDs of the
telegrams. The number of available PCDs depends on the
telegram type. PCDs contain the actual data values of the
selected parameters.
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
Function:
[18]
[19]
[20]
[21]
[22]
[23]
[351] Ramp 2 Ramp up time
[352] Ramp 2 Ramp down time
[380] Jog Ramp Time
[381] Quick Stop Time
[412] Motor Speed Low Limit
[Hz]
[414] Motor Speed High Limit
[Hz]
[590] Digital & Relay Bus
Control
[676] Terminal45 Output Bus
Control
[696] Terminal 42 Output Bus
Control
[894] Bus Feedback 1
FC Port CTW
FC Port REF
None
[1500] Operation Hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor Current
[1615] Frequency [%]
[1616] Torque [Nm]
[1618] Motor Thermal
[1630] DC Link Voltage
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1638] SL Controller State
[1650] External Reference
[1652] Feedback [Unit]
Function:
Function:
