Parameter Descriptions
[41] Latch prec
stop inv
[51] External
interlock
4 4
[58] DigiPot
Hoist
[60] Counter A
[61] Counter A
[62] Reset
Counter A
[63] Counter B
[64] Counter B
[65] Reset
Counter B
[72] PID error
inverse
[73] PID reset I-
part
[74] PID enable
[150] Go To
Home
[151] Home Ref.
Switch
[155] HW Limit
Positive
[156] HW Limit
Negative
[157] Pos. Quick
Stop Inv
[160] Go To
Target Pos.
54
®
VLT
Send a latched stop signal when the precise
stop function is activated in
parameter 1-83 Precise Stop Function. The
latched precise stop inverse function is
available for terminals 18 or 19.
This function makes it possible to give an
external fault to the frequency converter. This
fault is treated as an internally generated
alarm.
(Terminal 29 or 33 only) Input for increment
counting in the SLC counter.
(Terminal 29 or 33 only) Input for decrement
counting in the SLC counter.
Input for reset of counter A.
(Terminal 29 or 33 only) Input for increment
counting in the SLC counter.
(Terminal 29 or 33 only) Input for decrement
counting in the SLC counter.
Input for reset of counter B.
Invert the resulting error from the process PID
controller. Available only if
parameter 1-00 Configuration Mode is set to [6]
Surface Winder or [7] Extended PID Speed OL.
Reset the I-part of the process PID controller.
Equivalent to parameter 7-40 Process PID I-part
Reset. Available only when
parameter 1-00 Configuration Mode is set to [6]
Surface Winder or [7] Extended PID Speed OL.
This option enables the extended process PID
controller. Equivalent to
parameter 7-50 Process PID Extended PID.
Available only if parameter 1-00 Configuration
Mode is set to [7] Extended PID Speed OL.
The frequency converter moves to the home
position.
Indicate the status of the home referenced
switch. On means that the home position is
reached, off means that the home position is
not reached.
The positive hardware position limit is
exceeded. This option is active on the falling
edge.
The negative hardware position limit is
exceeded. This option is active on the falling
edge.
Stop the frequency converter during
positioning with the ramp time that is set in
parameter 32-81 Motion Ctrl Quick Stop Ramp.
This option is only effective when
parameter 37-00 Application Mode is set to [2]
Position Control.
The frequency converter moves to the target
position. This option is only effective when
Danfoss A/S © 07/2016 All rights reserved.
Midi Drive FC 280
[162] Pos. Idx
Bit0
[163] Pos. Idx
Bit1
[164] Pos. Idx
Bit2
[171] Limit
switch cw
inverse
[172] Limit
switch ccw
inverse
5-10 Terminal 18 Digital Input
Option: Function:
[8] Start Functions are described in parameter group 5-1*
*
Digital Inputs.
5-11 Terminal 19 Digital Input
Option:
[10] Reversing Functions are described in parameter group 5-1*
*
5-12 Terminal 27 Digital Input
Option:
[2] Coast inverse Functions are described in parameter group
*
5-13 Terminal 29 Digital Input
Option:
[14] Jog
*
[32] Pulse time based
5-14 Terminal 32 Digital Input
Option:
[0] No operation
*
[82] Encoder input B
5-15 Terminal 33 Digital Input
Option:
[0] No operation
*
[32] Pulse time based
[81] Enocder input A
parameter 37-00 Application Mode is set to [2]
Position Control.
Position index bit 0. This option is only
effective when parameter 37-00 Application
Mode is set to [2] Position Control.
Position index bit 1. This option is only
effective when parameter 37-00 Application
Mode is set to [2] Position Control.
Position index bit 2. This option is only
effective when parameter 37-00 Application
Mode is set to [2] Position Control.
Function:
Digital Inputs.
Function:
5-1* Digital Inputs.
Function:
Functions are described in parameter
group 5-1* Digital Inputs.
Function:
Functions are described in parameter
group 5-1* Digital Inputs.
Function:
Functions are described in parameter
group 5-1* Digital Inputs.
