Parameter Descriptions

4.4 Parameters: 3-** Reference/Ramps

3-00 Reference Range
Option: Function:
[0] Min - Max Select the range of the reference signal and
*
the feedback signal. Signal values can be
positive only, or positive and negative.
[1] -Max - For both positive and negative values (both
+Max directions), relative to parameter 4-10 Motor
Speed Direction.
3-01 Reference/Feedback Unit
Option: Function:
Select the unit for process PID control references
and feedbacks.
[0] None
[1] %
[2] RPM
[3] Hz
[4] Nm
[5] PPM
[10] 1/min
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
MG07C302
Programming Guide
3-01 Reference/Feedback Unit
Option:
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[150] lb ft
[160] °F
[170] psi
[171] lb/in2
[172] in WG
[173] ft WG
[180] HP
3-02 Minimum Reference
Range:
0
Reference
Feedback
Unit
*
3-03 Maximum Reference
Range:
Size
related
*
3-04 Reference Function
Option:
[0] Sum
*
[1] External/
Preset
Danfoss A/S © 07/2016 All rights reserved.
Function:
Function:
[ 0 - 4999 Enter the minimum reference. The
Reference minimum reference is the lowest value
Feedback obtainable by summing all references.
Unit] The minimum reference is active only
when parameter 3-00 Reference Range is
set to [0] Min.–Max.
The minimum reference unit matches:
•
The option in
parameter 1-00 Configuration
Mode.
•
The unit selected in
parameter 3-01 Reference/
Feedback Unit.
Function:
[-4999.0 - 4999 Enter the maximum reference. The
ReferenceFeed- maximum reference is the highest
backUnit] value obtainable by summing all
references.
The maximum reference unit
matches:
•
The option selected in
parameter 1-00 Configuration
Mode.
•
The unit selected in
parameter 3-00 Reference
Range.
Function:
Sum both external and preset reference
sources.
Use either the preset or the external
reference source. Shift between external and
preset via a command or a digital input.
