2-** Brakes - Danfoss VLT Midi Drive FC 280 Programming Manual

Parameter Lists
Parameter # Parameter description
1-72 Start Function
1-73 Flying Start
1-75 Start Speed [Hz]
1-76 Start Current
1-78 Compressor Start Max Speed [Hz]
Compressor Start Max Time to
1-79 Trip
1-8* Stop Adjustments
1-80 Function at Stop
Min Speed for Function at Stop
1-82 [Hz]
1-83 Precise Stop Function
1-84 Precise Stop Counter Value
Precise Stop Speed Compensation
1-85 Delay
1-88 AC Brake Gain
1-9* Motor Temperature
1-90 Motor Thermal Protection
1-93 Thermistor Source

5.2.3 2-** Brakes

Parameter # Parameter description
2-0* DC-Brake
2-00 DC Hold/Motor Preheat Current
2-01 DC Brake Current
2-02 DC Braking Time
2-04 DC Brake Cut In Speed
2-06 Parking Current
2-07 Parking Time
2-1* Brake Energy Funct.
2-10 Brake Function
2-11 Brake Resistor (ohm)
2-12 Brake Power Limit (kW)
2-14 Brake voltage reduce
2-16 AC Brake, Max current
2-17 Over-voltage Control
2-19 Over-voltage Gain
2-2* Mechanical Brake
2-20 Release Brake Current
2-22 Activate Brake Speed [Hz]
2-23 Activate Brake Delay
MG07C302
Programming Guide
Default value 4 set-up
[2] Coast/delay
time All set-ups
[0] Disabled All set-ups
Size Related All set-ups
Size Related All set-ups
0 Hz All set-ups
5 s All set-ups
[0] Coast All set-ups
0 Hz All set-ups
[0] Precise ramp
stop All set-ups
100000 N/A All set-ups
10 ms All set-ups
1.4 N/A All set-ups
[0] No protection All set-ups
[0] None All set-ups
Default value 4 set-up
50 % All set-ups
50 % All set-ups
10 s All set-ups
0 Hz All set-ups
100 % All set-ups
3 s All set-ups
[0] Off All set-ups
Size Related All set-ups
Size Related All set-ups
0 V All set-ups
100 % All set-ups
[0] Disabled All set-ups
100 % All set-ups
0 A All set-ups
0 Hz All set-ups
0 s All set-ups
Danfoss A/S © 07/2016 All rights reserved.
Change during Conversion
operation index
TRUE -
TRUE -
TRUE -1
TRUE -2
TRUE -1
TRUE -1
TRUE -
TRUE -1
FALSE -
TRUE 0
TRUE -3
TRUE -1
TRUE -
FALSE -
Change during Conversion
operation index
TRUE 0
TRUE 0
TRUE -1
TRUE -1
TRUE 0
TRUE -1
TRUE -
FALSE -1
TRUE 0
FALSE 0
TRUE -1
TRUE -
TRUE 0
TRUE -2
TRUE -1
TRUE -1
Type
Uint8
Uint8
Uint16
Uint32
Uint16
Uint8
5 5
Uint8
Uint16
Uint8
Uint32
Uint8
Uint16
Uint8
Uint8
Type
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint8
Uint16
Uint32
uint16
Uint16
Uint8
Uint16
Uint32
Uint16
Uint8
107
