3.1 Local Control Panel Operation

3 3
The frequency converter supports numerical local control
panel (NLCP), graphic local control panel (GLCP), and blind
cover. This section describes the operations with NLCP and
GLCP.
NOTICE
The frequency converter can also be programmed from
the MCT 10 Set-up Software on PC via RS485 communi-
cation port or USB port. This software can be ordered
using ordering number 130B1000 or downloaded from
the Danfoss website: www.danfoss.com/BusinessAreas/
DrivesSolutions/softwaredownload.

3.1.1 Numeric Local Control Panel (LCP)

The numerical local control panel (NLCP) is divided into 4
functional sections.
A. Numeric display.
B. Menu key.
C. Navigation keys and indicator lights (LEDs).
D. Operation keys and indicator lights (LEDs).
1
A
2
4
B
9
C
On
6
Warn
8
Hand
D
13
Illustration 3.1 View of the NLCP
12
Setup 1
Status Quick Main
Menu Menu
Menu
OK
Alarm
O
Auto
Reset
On
14
Danfoss A/S © 07/2016 All rights reserved.
®
VLT Midi Drive FC 280
A. Numeric display
The LCD display is backlit with 1 numeric line. All data is
shown in the NLCP.
The set-up number shows the active set-up and the edit
set-up. If the same set-up acts as both active and edit set-
up, only that set-up number is shown (factory setting).
1
When active and edit set-up differ, both numbers are
shown in the display (for example set-up 12). The number
flashing indicates the edit set-up.
2 Parameter number.
3 Parameter value.
Motor direction is shown at the bottom left of the display.
4
A small arrow indicates the direction.
The triangle indicates whether the LCP is in Status, Quick
5
Menu, or Main Menu.
Table 3.1 Legend to Illustration 3.1, Section A
Illustration 3.2 Display Information
B. Menu key
To select between Status, Quick Menu, or Main Menu,
press [Menu].
3
C. Indicator lights (LEDs) and navigation keys
Indicator
5
6
10
11
7
12
8
10
Table 3.2 Legend to Illustration 3.1, Indicator Lights (LEDs)
On
15
Setup 1234
n1 n2 n3
p5 p4
INDEX
p3 p2
Light
ON turns on when the frequency
converter receives power from the
On Green
mains voltage, a DC bus terminal, or a
24 V external supply.
When warning conditions are met, the
yellow WARN LED turns on, and text
Warn Yellow
appears in the display area identifying
the problem.
A fault condition causes the red alarm
Alarm Red LED to flash and an alarm text is
shown.
AHP
VkW
srpm
Hz%
p1
Function
MG07C302
