Parameter Descriptions
[160] No alarm The output is high when no alarm is
present.
[161] Running The output is high when the frequency
reverse converter is running counterclockwise
(the logical product of the status bits
Running AND Reverse).
[165] Local reference
active
[166] Remote ref
active
[167] Start command The output is high when there is an
active active start command, and no stop
command is active.
[168] Drive in hand The output is high when the frequency
mode converter is in hand-on mode.
[169] Drive in auto The output is high when the frequency
mode converter is in auto-on mode.
[170] Homing The homing operation is completed. This
Completed option is only effective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[171] Target Position The target position is reached. This
Reached option is only effective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[172] Position A fault occurred in the positioning
Control Fault process. Refer to parameter 37-18 Pos. Ctrl
Fault Reason for details about the fault.
This option is only effective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[173] Position Mech Select mechanical control for positioning.
Brake This option is only effective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[190] STO function
active
[193] Sleep mode The frequency converter/system has
entered sleep mode. See parameter group
22-4* Sleep Mode.
[194] Broken belt A broken-belt condition has been
detected. See parameter group 22-4* Sleep
Mode.
[239] STO function
fault
5-34 On Delay, Digital Output
Range:
0.01 s [0 - 600 s]
*
5-35 Off Delay, Digital Output
Range:
0.01 s [0 - 600 s]
*
MG07C302
Programming Guide

4.6.3 5-4* Relay

Parameters for configuring the timing and the output
functions for the relay.
The parameter shows 1 relay.
5-40 Function Relay
Option:
[0]
[1]
*
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
Function:
[16]
Function:
[17]
[18]
Danfoss A/S © 07/2016 All rights reserved.
Function:
No operation Default setting for all digital outputs.
Control Ready The control card is ready.
Drive ready The frequency converter is ready to
operate. Mains and control supplies are
OK.
Drive rdy/rem ctrl The frequency converter is ready for
operation, and in auto-on mode.
Stand-by / no Ready for operation. No start or stop
warning commands have been applied. No
warnings are active.
Running The motor runs, and a shaft torque is
present.
Running / no The output speed is higher than the
warning speed set in parameter 1-82 Min Speed
for Function at Stop [Hz]. The motor is
running and no warnings are present.
Run in range/no The motor runs within the
warn programmed current ranges set in
parameter 4-50 Warning Current Low.
Run on ref/no The motor runs at reference speed. No
warn warnings.
Alarm An alarm activates the output. No
warnings.
Alarm or warning An alarm or warning activates the
output.
At torque limit The torque limit set in
parameter 4-16 Torque Limit Motor
Mode or parameter 4-17 Torque Limit
Generator Mode has been exceeded.
Out of current The motor current is outside the range
range set in parameter 4-18 Current Limit.
Below current, The motor current is lower than set in
low parameter 4-50 Warning Current Low.
Above current, The motor current is higher than set in
high parameter 4-51 Warning Current High.
Out of frequency The output speed/frequency exceeds
range the limit that is set in
parameter 4-40 Warning Freq. Low and
parameter 4-41 Warning Freq. High.
Below frequency, The output frequency is lower than the
low setting in parameter 4-40 Warning Freq.
Low.
Above frequency, The frequency is higher than the
high setting in parameter 4-41 Warning Freq.
High.
Out of feedb. The feedback is outside the range set
range in parameter 4-56 Warning Feedback
