Command
PRAT?
HRAT
VRAT?
FRAT?
HTOT
HRES
VTOT
VRES
SCAN
RFLD
HSPD
HSPW
HVPD?
VSPD
VSPW
EQUB
EQUA
HVSA
FSPD
FSPW
PSHD
PSVD
PSPW
PSVW
PSPM
882 Video Test Instrument User Guide (Rev A.35)
Parameters (Video Timing)
Type
Rates
Rates
Rates
Rates
Horizontal
Horizontal
Vertical
Vertical
Vertical
Vertical
Horizontal Sync
Horizontal Sync
Horizontal Sync
Vertical Sync
Vertical Sync
Composite Sync
Composite Sync
Composite Sync
Frame Sync
Frame Sync
Probe Sync
Probe Sync
Probe Sync
Probe Sync
Probe Sync
Parameters (Audio Signal and Timing)
Command Type
CAUD Encoding
DASI Interface
Description
Get current pixel rate setting
Set line frequency
Get current vertical (field) rate
Get current vertical rate setting for frame
Set total number of pixels per horizontal line
Set number of active pixels per line
Set total number of lines per vertical frame
Set number of active pixels per frame
Set number of fields scanned per frame
Enable/disable identical video information
output for each field of interlaced format
Set horizontal sync pulse delay
Set width of horizontal sync pulse
Get pixel delay between horizontal and vertical
sync pulses
Set vertical sync pulse delay
Set vertical sync pulse width
Set equalization interval before vertical sync
pulse
Set equalization interval after vertical sync pulse
Set pixel serration period
Set frame sync pulse delay
Set width of frame sync pulse
Set line delay (in pixels)
Set vertical delay
Set pixel width
Set vertical width
Set lines in frame where probe pulse occurs
Description
Set digital audio clips
Set digital audio signal interface
