Cloning a generator using the Generator FTP Browser

882 Video Test Instrument User Guide (Rev A.35)
8. On the target generator, press the Tools key. The Tools menu appears on the
generator's display as shown below.
System
Sequence
Probe
AFC
9. Choose the System item by pressing the adjacent soft key. The System menu appears
on the generator's display as shown below.
Clock
CalFactor
Network
Serial
10. Choose the Clone item by pressing the adjacent soft key. The Clone menu appears on
the generator's display as shown below.
Capture
11. Choose the Restore item by pressing the adjacent soft key.
A progress indicator appears.
12. Restart the generator from flash memory.
This section provides procedures for cloning a generator with a PC directly connected to a
generator. You will find this cloning method procedure useful if you do not have a PC Card.
To complete this procedure you connect the Ethernet crossover cable to the Ethernet
ports of both the PC and the generator. If your generators are networked over an Ethernet
LAN, see "Cloning 882s using the 882 FTP
During this procedure, you will copy the files from the source generator to the PC,
disconnect the source generator and connect the target generator, and then copy the files
from the PC to the target generator. You must know the IP address of both generators.
To clone a generator using the Generator FTP Browser:
1. Connect the source generator to the PC using an Ethernet crossover cable between
the Ethernet ports on the PC and the generator.
Reports
ImgShift
Analyzer
CEC
Clone*
Server
About
GPib
ite
Restore
Browser" on page 155.
